Video Scope

  • Ø from 4mm (0.16”) to 11mm (0.43”)
  • Working Lengths from 1 meter (3.3 foot)
to 30 meters (98 foot)
  • Fast (up to 60 fps), High Resolution CMOS video camera chip
  • 3.5” Color LCD Display, with 720x480 pixel resolution
  • Image (JPEG )/Video (MPEG4) File capture
  • AV output (PAL/NTSC selectable)
  • 2 GB SD card for file capture/storage
  • USB port (1.1/2.0) to transfer data to a PC
  • LED Illumination, with variable intensity adjustment
  • Working temperature -20° to+60° C
  • Rechargeable Li-Polymer Battery with up to 4 hours of continuous
Insertion probe :
  • Diameter : 5.5mm (0.22")

  • Length : OPTIONAL 1M (3.3'), 2M (6.5'), 3M (9.8') or 10M (33'), 20M (66'), 30M (98')
  • Articulation : no articulation
  • CMOS Image Sensor Resolution
  • Resolution 720(H)*480(V)
  • 67° Field of View (FOV)

  • 0°Direction of view
• 1cm-8cm Focal range
  • Waterproof insertion tube only (IP57)
  • Light Source: 4-6 White LEDs
Imaging Hub :
  • 3.5”TFT LCD Monitor 320*240 Pixels
  • Interface : Mini usb 1.1/ AV out/ Av in/
  • MPG4(saved as AVI) Compression Format
  •
JPEG Still Image Storage Format
  •
TV system : NTSC & PAL
  •
Power : DC5V
  •
Battery : Rechargeable Li-Polymer Battery (3.7V)
  • Language: 16 Languages
    •
